Digital Display Solutions

Retail – Smart City – School –Outdoor

The FAB PANEL WIDE TOUCH DISPLAY in 55inch to 82 inch is a Super resolution Color Active Matrix Liquid Crystal Display with an integral the Source PCB and Gate implanted on Panel (GIP). The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in the normally black mode. It has a diagonally measured active display area with QWUXGA resolution (2160 vertical by 3840 horizontal pixel array)




Display Panel with Latest Technology



The FAB PANEL WIDE TOUCH is a Digital Display with 55-82 inch in Size LCD screen that  offers productivity in a compact body with multiple connectivity .

The Model  has passed extremely stringent tests for performance and has received certifications from a reputable third party.

DESIGNED FOR PERFORMANCE

The Digital Signage is deployed with the best in class Performance with 2500 NTS Brightness for clear Outdoor resolution even with the SUN rays falling on it and will give crisp , clear images in FULL HD to 4K format .


Powerful and Compact

Sub-pixels a  re constructed with Red, Green, Blue and White. Each pixel is divided into RGB or WRG or BWR or GBW or dots which are arranged in vertical stripes. Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot. & can present a palette of more than 1.07 Billion colors. It has been designed to apply the 10-bit 8 Lane VbyOne interface.

It  supports LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.

FAB PANEL WIDE TOUCH DISPLAY 75  – Specifications & Optional Features

75 inch Large Display Sign LCD 2500 NITS is a Color Active Matrix Liquid Crystal Display with an integral the Source PCB and Gate



Transmissive type display operating in black mode.

54.64 inch diagonally measured active display area

QWUXGA resolution

(2160 vertical by 3840 horizontal pixel array).

Sub-pixels with Red, Green, Blue and White.

Each pixel is divided into RGB or WRG or BWR or GBW or dots which are arranged in vertical stripes.

Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.


A Palette of more than 1.07 Billion colors.

Designed to apply 10-bit 8 Lane V by One  interface.


Supports LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.
Dimension -   1245.2 cm ( H) x 716 (V) x 40 ( D )
